22MP-1 X 1-316L-7 – TC X NPT-FEMALE ADAPTER
Technical Details
| Range | Connections |
| Product Model | Tri-Clover 3A Adapters |
| Size | 1" |
| Size mm | 25.40 x 25.40 |
| Second size | 1" |
| Material | 316L |
| Finish | #7 (ID=32/OD=32µin) |
| Connection type | Tri-Clamp NPT female |
| Standard | Hygienic |
| Design | 22MP |
| Dimension A | 41.30 |
| Dimension A, Inch | 1.63 |
| Weight – Net (Kg) | 0.85 kg |
