23BMP-3 X 3/4-316L-7 – TC THERMOMETER CAP, POLISHED
Technical Details
| Range | End caps |
| Product Model | Tri-Clover 3A Thermometer Caps |
| Size | 3" |
| Size mm | 76.20 x 19.00 |
| Second size | 0.75" |
| Material | 316L |
| Finish | #7 (ID=32/OD=32µin) |
| Connection type | Tri-Clamp NPT female |
| Standard | Hygienic |
| Design | 23BMP NPT |
| Dimension A | 90.90 |
| Dimension A, Inch | 3.58 |
| Dimension B | 15.90 |
| Dimension B, Inch | 0.63 |
| Weight – Net (Kg) | 0.33 kg |
