ANTI VACUUM VALVE – @250/10″ FLANGE TYPE 100MMH2O
Technical Details
| Allowable pressure ps bar | 4 |
| Allowable pressure ps psi | 58 |
| Bolts | 8xM16 |
| Dimension bc inch | 12.99 |
| Dimension bc mm | 330 |
| Dimension h1 inch | 12.80 |
| Dimension h1 mm | 325 |
| Dimension h2 inch | 1.18 |
| Dimension h2 mm | 30 |
| Dimension w inch | 23.62 |
| Dimension w mm | 600 |
| Elastomer | EPDM |
| Inner diameter inch | 9.84 |
| Inner diameter mm | 250 |
| Inside surface quality | Ra ≤ 0.8 μm |
| Nominal size inch | 10 |
| Nominal size mm | 250 |
| Opening pressure range mmh2o | 100 |
| Opening pressure range psi | 0.035-0.43 |
| Other steel parts | 1.4307 (AISI 304L) |
| Outer diameter inch | 14.57 |
| Outer diameter mm | 370 |
| Product wetted polymers | PEEK |
| Product wetted steel part | 1.4404 (316L) |
| Valve type | Flange mounted valve |
| Weight – Net (Kg) | 25.29 kg |
