ANTI VACUUM VALVE – @150/6″ FLANGE TYPE 350MMH2O
Technical Details
| Nominal size mm | 150 |
| Nominal size inch | 6 |
| Elastomer | EPDM |
| Product wetted steel part | 1.4404 (316L) |
| Other steel parts | 1.4307 (AISI 304L) |
| Product wetted polymers | PEEK |
| Bolts | 8xM16 |
| Inside surface quality | Ra ≤ 0.8 μm |
| Valve type | Flange mounted valve |
| Opening pressure range mmh2o | 350 |
| Opening pressure range psi | 0.035-0.7 |
| Allowable pressure ps bar | 6 |
| Allowable pressure ps psi | 87 |
| Outer diameter mm | 270 |
| Outer diameter inch | 10.63 |
| Inner diameter mm | 150 |
| Inner diameter inch | 5.91 |
| Dimension bc mm | 230 |
| Dimension bc inch | 9.06 |
| Dimension h1 mm | 325 |
| Dimension h1 inch | 12.80 |
| Dimension h2 mm | 30 |
| Dimension h2 inch | 1.18 |
| Dimension w mm | 550 |
| Dimension w inch | 21.65 |
| Weight – Net (Kg) | 12.66 kg |
