Connection type: Weld ends
Design: B288S
Dimension A: 97.20
Dimension A, Inch: 3.827
Dimension B: 93.90
Dimension B, Inch: 3.697
Finish: SF4(PM) (ID=15EP/OD=32µin)
Material: 316L
OD/ID x t: 38.10/34.80 x 1.65
OD/ID x t, inch: 1.500/1.370 x 0.065
Product model: Tri-Clover BPE Bends 88
Range: Bends
Size: 1.5″
Standard: UltraPure
Weight – Net (Kg): 0.24 kg
Log in or register to view prices.
Log in or register to view and purchase products.
B288S-1 1/2-316L-PM – BPE WELD 88 15RAEP/POL OD SF4
| Connection type | Weld ends |
| Design | B288S |
| Dimension A | 97.20 |
| Dimension A, Inch | 3.827 |
| Dimension B | 93.90 |
| Dimension B, Inch | 3.697 |
| Finish | SF4(PM) (ID=15EP/OD=32µin) |
| Material | 316L |
| OD/ID x t | 38.10/34.80 x 1.65 |
| OD/ID x t, inch | 1.500/1.370 x 0.065 |
| Product model | Tri-Clover BPE Bends 88 |
| Range | Bends |
| Size | 1.5" |
| Standard | UltraPure |
| Weight – Net (Kg) | 0.24 kg |
B288S-1 1/2-316L-PM
