B31MS-2 1/2 X 2-316L-PL – BPE ConRed-TCxWeld 20Ra, SF1
Technical Details
| Range | Reducers |
| Product model | Tri-Clover BPE Reducers Concentric |
| Size | 2.5" |
| Material | 316L |
| Second size | 2" |
| Finish | SF1(PL) (ID=20/OD=32µin) |
| Connection type | Tri-Clamp and Weld |
| Standard | ASME BPE |
| Design | B31MS |
| OD/ID x t | 63.50/60.20 x 1.65 |
| OD/ID x t, inch | 2.500/2.370 x 0.065 |
| Dimension A, Inch | 3.00 |
| Dimension A | 76.20 |
| Weight – Net (Kg) | 0.73 kg |
