Connection type: Weld and Weld and Tri-Clamp
Design: B7IWWMS
Dimension A: 63.50
Dimension A, Inch: 2.50
Dimension B: 22.20
Dimension B, Inch: 0.88
Finish: SF4(PM) (ID=15EP/OD=32µin)
Material: 316L
OD/ID x t: 12.70/9.40 x 1.65
OD/ID x t, inch: 0.500/0.370 x 0.065
Product model: Tri-Clover BPE Reducing Tees
Range: Tees
Second size: 1.5″
Size: 0.5″
Standard: ASME BPE
Weight – Net (Kg): 0.38 kg
Log in or register to view prices.
Log in or register to view and purchase products.
B7IWWMS-1/2 X 1 1/2-316L-PM – BPE WXTC INSTR’T T 15RAEP SF4
| Connection type | Weld and Weld and Tri-Clamp |
| Design | B7IWWMS |
| Dimension A | 63.50 |
| Dimension A, Inch | 2.50 |
| Dimension B | 22.20 |
| Dimension B, Inch | 0.88 |
| Finish | SF4(PM) (ID=15EP/OD=32µin) |
| Material | 316L |
| OD/ID x t | 12.70/9.40 x 1.65 |
| OD/ID x t, inch | 0.500/0.370 x 0.065 |
| Product model | Tri-Clover BPE Reducing Tees |
| Range | Tees |
| Second size | 1.5" |
| Size | 0.5" |
| Standard | ASME BPE |
| Weight – Net (Kg) | 0.38 kg |
B7IWWMS-1/2 X 1 1/2-316L-PM
