Connection type: Weld and Tri-Clamp and Weld
Design: B7RWWM
Dimension A: 60.30
Dimension A, Inch: 2.38
Dimension B: 73.00
Dimension B, Inch: 2.88
Finish: SF1(PL) (ID=20/OD=32µin)
Material: 316L
OD/ID x t: 38.10/34.80 x 1.65
OD/ID x t, inch: 1.500/1.370 x 0.065
Product model: Tri-Clover BPE Reducing Tees
Range: Tees
Second size: 0.5″
Size: 1.5″
Standard: UltraPure
Weight – Net (Kg): 0.22 kg
Log in or register to view prices.
Log in or register to view and purchase products.
B7RWWM-1 1/2X1/2 316L PL – BPE RED T WXWXTC 20RA SF1
| Connection type | Weld and Tri-Clamp and Weld |
| Design | B7RWWM |
| Dimension A | 60.30 |
| Dimension A, Inch | 2.38 |
| Dimension B | 73.00 |
| Dimension B, Inch | 2.88 |
| Finish | SF1(PL) (ID=20/OD=32µin) |
| Material | 316L |
| OD/ID x t | 38.10/34.80 x 1.65 |
| OD/ID x t, inch | 1.500/1.370 x 0.065 |
| Product model | Tri-Clover BPE Reducing Tees |
| Range | Tees |
| Second size | 0.5" |
| Size | 1.5" |
| Standard | UltraPure |
| Weight – Net (Kg) | 0.22 kg |
B7RWWM-1 1/2X1/2 316L PL
