B7RWWW-2 X 1/2-316L-PL – BPE WELD RED T 20RA/POL SF1
Technical Details
| Range | Tees |
| Product model | Tri-Clover BPE Reducing Tees |
| Size | 2" |
| Material | 316L |
| Second size | 0.5" |
| Finish | SF1(PL) (ID=20/OD=32µin) |
| Connection type | Weld ends |
| Standard | ASME BPE |
| Design | B7RWWW |
| OD/ID x t | 50.80/47.50 x 1.65 |
| OD/ID x t, inch | 2.000/1.870 x 0.065 |
| Dimension A, Inch | 2.88 |
| Dimension A | 73.00 |
| Dimension B, Inch | 2.63 |
| Dimension B | 66.70 |
| Weight – Net (Kg) | 0.36 kg |
