B7RWWW-3 X 1 1/2-316L-PL – BPE WELD RED T 20RA/POL SF1
Technical Details
| Range | Tees |
| Product model | Tri-Clover BPE Reducing Tees |
| Size | 3" |
| Material | 316L |
| Second size | 1.5" |
| Finish | SF1(PL) (ID=20/OD=32µin) |
| Connection type | Weld ends |
| Standard | ASME BPE |
| Design | B7RWWW |
| OD/ID x t | 76.20/72.90 x 1.65 |
| OD/ID x t, inch | 3.000/2.870 x 0.065 |
| Dimension A, Inch | 3.38 |
| Dimension A | 85.70 |
| Dimension B, Inch | 3.13 |
| Dimension B | 79.40 |
| Weight – Net (Kg) | 0.7 kg |
