Connection type: Weld ends
Design: B7RWWW
Dimension A: 104.80
Dimension A, Inch: 4.13
Dimension B: 98.40
Dimension B, Inch: 3.88
Finish: SF1(PL) (ID=20/OD=32µin)
Material: 316L
OD/ID x t: 101.60/97.38 x 2.11
OD/ID x t, inch: 4.000/3.834 x 0.083
Product model: Tri-Clover BPE Reducing Tees
Range: Tees
Second size: 2″
Size: 4″
Standard: ASME BPE
Weight – Net (Kg): 1.32 kg
Log in or register to view prices.
Log in or register to view and purchase products.
B7RWWW-4 X 2-316L-PL …. – BPE WELD RED T 20RA/POL SF1
| Connection type | Weld ends |
| Design | B7RWWW |
| Dimension A | 104.80 |
| Dimension A, Inch | 4.13 |
| Dimension B | 98.40 |
| Dimension B, Inch | 3.88 |
| Finish | SF1(PL) (ID=20/OD=32µin) |
| Material | 316L |
| OD/ID x t | 101.60/97.38 x 2.11 |
| OD/ID x t, inch | 4.000/3.834 x 0.083 |
| Product model | Tri-Clover BPE Reducing Tees |
| Range | Tees |
| Second size | 2" |
| Size | 4" |
| Standard | ASME BPE |
| Weight – Net (Kg) | 1.32 kg |
B7RWWW-4 X 2-316L-PL ….
