B7WWMS-1/2-316L-PM – BPE S/O WXTC T 15RA/POL,SF4
Technical Details
| Range | Tees |
| Product model | Tri-Clover BPE Tees Short |
| Size | 0.5" |
| Material | 316L |
| Finish | SF4(PM) (ID=15EP/OD=32µin) |
| Connection type | Weld and Weld and Short Tri-Clamp |
| Standard | ASME BPE |
| Design | B7WWMS |
| OD/ID x t | 12.70/9.40 x 1.65 |
| OD/ID x t, inch | 0.500/0.370 x 0.065 |
| Dimension A, Inch | 1.88 |
| Dimension A | 47.60 |
| Dimension B, Inch | 1.00 |
| Dimension B | 25.40 |
| Weight – Net (Kg) | 0.06 kg |
