B7WWW-4-316L- PM – BPE TEE W 15RA/POL OD SF4
Technical Details
| Range | Tees |
| Product model | Tri-Clover BPE Tees Equal |
| Size | 4" |
| Material | 316L |
| Finish | SF4(PM) (ID=15EP/OD=32µin) |
| Connection type | Weld ends |
| Standard | ASME BPE |
| Design | B7WWW |
| OD/ID x t | 101.60/97.38 x 2.11 |
| OD/ID x t, inch | 4.000/3.834 x 0.083 |
| Dimension A, Inch | 4.13 |
| Dimension A | 104.80 |
| Weight – Net (Kg) | 1.25 kg |
