BALL VALVE SBV-DN80-M/M-MAN – BALL VALVE SBV-DN80-M/M-MAN – Q-CAVITY FILLER
Technical Details
| Size din | DN80 |
| Connection type | BS Male/Male |
| Size mm | 76.1 |
| Size inch | 3.0 |
| Product wetted steel part | 1.4404 (316L) |
| Other steel parts | 1.4307 (304) |
| Elastomer | Q (Silicone) |
| Other seals | NBR |
| Max product pressure | 0 to 1600 kPa (16 bar) |
| Max product pressure psi | 371 PSI |
| Actuator function | Standard |
| Actuation | Manual |
| Inside surface quality | Ra < 0.8 µm |
| Outside surface quality | Blasted |
| Temperature range operating | +0 °C to +95 °C |
| Temperature range operating fahrenheit | +32 °F to +203 °F |
| Min product pressure | Full vacuum |
| Min product pressure psi | Full vacuum |
| Temperature range steralization | 0°C to 90°C |
| Temperature range steralization fahrenheit | to +194 °F |
| Temperature range ambient air | +4 °C to +45 °C |
| Temperature range ambient air fahrenheit | +39 °F to +113 °F |
| Body combination | Standard handle |
| Outer diameter mm | 85 |
| Inner diameter mm | 81 |
| Classification | II 2 G D |
| Dimension a mm | 159 |
| Dimension a inch | 6.26 |
| Dimension b mm | 163 |
| Dimension b inch | 6.42 |
| Dimension c mm | 180 |
| Dimension c inch | 7.09 |
| Dimension d mm | 156 |
| Dimension d inch | 6.14 |
| Dimension t mm | 2 |
| Weight – Net (Kg) | 12.5 kg |
