COARSE STRAINER LKVF 63.5MM – COARSE STRAINER LKVF 63.5MM – EPDM WELDING ENDS 2.0MM STRAINER ELEMENT
Technical Details
| Min product pressure bar | Full vacuum |
| Strainer type | LKVF Coarse Strainer |
| Temperature range celcius | -10 °C to 140 °C (EPDM) |
| Strainer area cm2 | 840 |
| Product wetted steel part | Acid-resistant steel AISI 316 |
| Other steel parts | AISI 304 Stainless Steel |
| Product wetted elastomers | EPDM |
| Surface finish | Semi-Bright |
| Material grades | NBR |
| Size mm | 63.5 |
| Strainer element perforation | 30% of open area |
| Mesh perforation diameter mm | 2 |
| Filter pattern mm | 3.5 |
| Connection type | Welding ends |
| Other connection types | DS, SMS, BS, IDF, Clamp |
| Dimension a mm | 460 |
| Dimension b mm | 352 |
| Dimension e mm | 94 |
| Outer diameter mm | 63.5 |
| Inner diameter mm | 60.3 |
| Dimension t mm | 1.6 |
| Weight – Net (Kg) | 1.23 kg |
