Connection type: Tri-Clamp and Weld
Design: KK short
Dimension A: 106.00
Dimension B: 28.00
Finish: HSF0 (ID=0.8/OD=1.6)
Material: 1.4404 (316L)
OD/ID x t: 85.00/81.00 x 2.00
OD1/ID1 x t1: 85.00/81.00 x 2.00
Product Model: DIN EN 10357-A Clamp Unions DIN 32676
Range: Ferrules
Size: DN80
Standard: DIN 32676
Weight – Net (Kg): 0.22 kg
Log in or register to view prices.
Log in or register to view and purchase products.
FERRULE KK DN80 HSF0 1.4404 – DIN 32676
| Connection type | Tri-Clamp and Weld |
| Design | KK short |
| Dimension A | 106.00 |
| Dimension B | 28.00 |
| Finish | HSF0 (ID=0.8/OD=1.6) |
| Material | 1.4404 (316L) |
| OD/ID x t | 85.00/81.00 x 2.00 |
| OD1/ID1 x t1 | 85.00/81.00 x 2.00 |
| Product Model | DIN EN 10357-A Clamp Unions DIN 32676 |
| Range | Ferrules |
| Size | DN80 |
| Standard | DIN 32676 |
| Weight – Net (Kg) | 0.22 kg |
FERRULE KK DN80 HSF0 1.4404
