HANDLE 1.1 FOR LKB POS.A – 2-POSITIONS 76,1/DN65-80
Technical Details
| Valve type | LKB |
| Handle design | Regulating with 2 positions |
| Size iso | 76.1 |
| Size din | DN65, DN80 |
| Size inch | 3 |
| Opening direction | Counter clockwise |
| Lockable handle | No |
| Handle padlock | No |
| Material | 1.4301 (304) |
| Dimension k inch | 6.70 |
| Dimension k mm | 170.3 |
| Dimension r inch | 1.50 |
| Dimension r mm | 38 |
| Dimension s inch | 0.39 |
| Dimension s mm | 10 |
| Dimension t inch | 1.19 |
| Dimension t mm | 30.2 |
| Weight – Net (Kg) | 0.4 kg |
