IM15 RJMIXER 2X8 100% 1½”RP – IM15 RJMIXER 2X8 100% 1½”RP –
Technical Details
| Mixer type | IM-15 |
| No of nozzels mm | 2 x Ø8 |
| No of nozzels inch | 2 x Ø0.31 |
| Connection type | Thread (1½” Rp-female (BSP)) |
| Tank mixer guide | 100% |
| Product wetted steel part | AISI 316 |
| Surface finish | Bright |
| Certificate | ATEX, 2.1 material certificate |
| Lubricant | Self-lubricating with the mixing/cleaning fluid |
| Dimension a mm | 297 |
| Dimension a inch | 11.70 |
| Dimension b mm | 170 |
| Dimension b inch | 6.69 |
| Dimension c mm | 50 |
| Dimension c inch | 1.5 |
| Dimension d mm | 204 |
| Dimension d inch | 8.03 |
| Dimension e mm | 78 |
| Dimension e inch | 3.07 |
| Dimension f mm | 152 |
| Dimension f inch | 5.98 |
| Dimension g mm | Ø216 |
| Dimension g inch | Ø8.50 |
| Dimension h mm | Ø264 |
| Dimension h inch | Ø10.39 |
| Dimension j mm | Ø180 |
| Dimension j inch | Ø7.09 |
| Flow at 5 bar | 14 |
| Flow 72 point 5 psi | 18.3 |
| Working pressure range bar | 2 – 12 |
| Working pressure range psi | 28 – 171 |
| Recommended pressure during mixing bar | 2 – 6 |
| Recommended pressure during mixing psi | 28 – 85 |
| Recommended pressure during cip bar | 5 – 6.5 |
| Recommended pressure during cip psi | 72 – 94 |
| Max working temperature | 95 °C |
| Max working temperature fahrenheit | 203 °F |
| Max ambient temperature | 140 °C |
| Max ambient temperature fahrenheit | 284 °F |
| Weight – Net (Kg) | 6.4 kg |
