IM20 RJMIXER 4X9 0% – IM20 RJMIXER 4X9 0% – 2″RP/F
Technical Details
| Mixer type | IM-20 |
| No of nozzels mm | 4 x Ø9 |
| No of nozzels inch | 4 x Ø0.35 |
| Connection type | Thread (2” Rp-female (BSP)) |
| Tank mixer guide | 0% |
| Product wetted steel part | AISI 316 |
| Surface finish | Bright |
| Certificate | ATEX, 2.1 material certificate |
| Lubricant | Self-lubricating with the mixing/cleaning fluid |
| Dimension a mm | 356 |
| Dimension a inch | 14.02 |
| Dimension b mm | 220 |
| Dimension b inch | 8.66 |
| Dimension c mm | 65 |
| Dimension c inch | 2 |
| Dimension d mm | 268 |
| Dimension d inch | 10.55 |
| Dimension e mm | 98 |
| Dimension e inch | 3.86 |
| Dimension f mm | 195 |
| Dimension f inch | 7.68 |
| Dimension g mm | Ø280 |
| Dimension g inch | Ø11.02 |
| Dimension h mm | Ø343 |
| Dimension h inch | Ø13.50 |
| Dimension j mm | Ø232 |
| Dimension j inch | Ø9.13 |
| Flow at 5 bar | 27.5 |
| Flow 72 point 5 psi | 36.0 |
| Working pressure range bar | 2 – 12 |
| Working pressure range psi | 28 – 171 |
| Recommended pressure during mixing bar | 2 – 6 |
| Recommended pressure during mixing psi | 28 – 85 |
| Recommended pressure during cip bar | 5 – 6.5 |
| Recommended pressure during cip psi | 72 – 94 |
| Max working temperature | 95 °C |
| Max working temperature fahrenheit | 203 °F |
| Max ambient temperature | 140 °C |
| Max ambient temperature fahrenheit | 284 °F |
| Weight – Net (Kg) | 11.8 kg |
