IM25 RJMIXER – IM25 RJMIXER – 2X15 0% 2 1/2″ RP EG. WITH E-GEAR
Technical Details
| Mixer type | IM-25 |
| No of nozzels mm | 2 x Ø15 |
| No of nozzels inch | 2 x Ø0.59 |
| Connection type | Thread (2½” Rp-female (BSP)) |
| Tank mixer guide | 0% |
| Product wetted steel part | AISI 316 |
| Surface finish | Bright |
| Certificate | ATEX, 2.1 material certificate |
| Lubricant | Self-lubricating with the mixing/cleaning fluid |
| Dimension a mm | 286 |
| Dimension a inch | 11.26 |
| Dimension b mm | 155 |
| Dimension b inch | 6.10 |
| Dimension c mm | 80 |
| Dimension c inch | 3.15 |
| Dimension d mm | 337 |
| Dimension d inch | 13.27 |
| Dimension e mm | 220 |
| Dimension e inch | 8.66 |
| Dimension f mm | Ø343 |
| Dimension f inch | Ø13.50 |
| Dimension g mm | Ø424 |
| Dimension g inch | Ø16.69 |
| Dimension h mm | Ø223 |
| Dimension h inch | Ø8.78 |
| Flow at 8 bar | 48 |
| Flow 116 psi | 62.8 |
| Working pressure range bar | 2 – 12 |
| Working pressure range psi | 28 – 171 |
| Recommended pressure during mixing bar | 4 – 8 |
| Recommended pressure during mixing psi | 57 – 114 |
| Recommended pressure during cip bar | 5 – 10 |
| Recommended pressure during cip psi | 72 – 145 |
| Max working temperature | 95 °C |
| Max working temperature fahrenheit | 205 °F |
| Max ambient temperature | 140 °C |
| Max ambient temperature fahrenheit | 284 °F |
| Weight – Net (Kg) | 10.7 kg |
