IN-LINE SIGHT GLASS DIN NW40 – W/ MALE PARTS AND SLEEVE 304
Technical Details
| Range | In-line sight glasses |
| Size din | DN40 |
| Material | 1.4301 (304) |
| Gasket material | NBR |
| Certificate | 3.1 Certificate |
| Standard | DIN 11851 |
| Dimension a mm | 164 |
| Dimension a inch | 6.46 |
| Dimension b mm | 38 |
| Dimension b inch | 1.5 |
| Dimension d mm | 5 |
| Dimension d inch | 0.2 |
| Dimension e mm | 65 x 1/6” |
| Dimension e inch | 65 x 1/6” |
| Weight – Net (Kg) | 1.5 kg |
