IN-LINE SIGHT GLASS DIN NW65 – W/ MALE PARTS AND SLEEVE 304
Technical Details
| Range | In-line sight glasses |
| Size din | DN65 |
| Material | 1.4301 (304) |
| Gasket material | NBR |
| Certificate | 3.1 Certificate |
| Standard | DIN 11851 |
| Dimension a mm | 191 |
| Dimension a inch | 7.52 |
| Dimension b mm | 66 |
| Dimension b inch | 2.6 |
| Dimension d mm | 5 |
| Dimension d inch | 0.2 |
| Dimension e mm | 95 x 1/6” |
| Dimension e inch | 95 x 1/6” |
| Weight – Net (Kg) | 2.74 kg |
