IN-LINE SIGHT GLASS DIN NW80 –
Technical Details
| Range | In-line sight glasses |
| Size din | DN80 |
| Material | 1.4301 (304) |
| Gasket material | NBR |
| Certificate | 3.1 Certificate |
| Standard | DIN 11851 |
| Dimension a mm | 209 |
| Dimension a inch | 8.23 |
| Dimension b mm | 81 |
| Dimension b inch | 3.19 |
| Dimension d mm | 5 |
| Dimension d inch | 0.2 |
| Dimension e mm | 110 x 1/4” |
| Dimension e inch | 110 x 1/4” |
| Weight – Net (Kg) | 3.68 kg |
