IN-LINE SIGHTGLASS DIN NW50 –
Technical Details
| Range | In-line sight glasses |
| Size din | DN50 |
| Material | 1.4301 (304) |
| Gasket material | NBR |
| Certificate | 3.1 Certificate |
| Standard | DIN 11851 |
| Dimension a mm | 168 |
| Dimension a inch | 6.61 |
| Dimension b mm | 50 |
| Dimension b inch | 1.97 |
| Dimension d mm | 5 |
| Dimension d inch | 0.2 |
| Dimension e mm | 78 x 1/6” |
| Dimension e inch | 78 x 1/6” |
| Weight – Net (Kg) | 3.66 kg |
