INSPECTION PORT LKD-440X320 – -060-E-1.4301, SS HANDLE, WITH HINGE
Technical Details
| Range | Oval covers |
| Size mm | 440×320 |
| Size inch | 17.32×12.6 |
| Material | 1.4301 (304) |
| Gasket material | EPDM |
| Frame height | 60 |
| Handle design | Handwheel |
| Handle material | Stainless steel |
| Hinge position | External |
| Hinge direction | Neutral |
| Inside surface quality | Acid pickled to Ra≤0.8 µm |
| Outside surface quality | Acid pickled to Ra≤3.0 µm |
| Pressure type | Static |
| Opening direction | Inwards |
| Min gasket temperature c | -15 |
| Min gasket temperature f | 5 |
| Max gasket temperature c | 90 |
| Max gasket temperature f | 194 |
| Dimension a mm | 440 |
| Dimension a inch | 17.32 |
| Dimension b mm | 320 |
| Dimension b inch | 12.6 |
| Dimension t mm | 8 |
| Dimension t inch | 0.31 |
| Lid thickness mm | 2 |
| Lid thickness inch | 0.08 |
| Certificate | 3.1 Certificate |
| Position on tank | Below liquid level – on side of the tank |
| Weight – Net (Kg) | 15.9 kg |
