KOLTEK VALVE AH53-101.6-CL/CL/ – KOLTEK VALVE AH53-101.6-CL/CL/ – CL-EPDM-316L
Technical Details
| Connection type | Clamp ends |
| Size mm | 101.6 |
| Size inch | 4 |
| Inside surface quality | Ra ≤ 0.4 μm |
| Outside surface quality | Blasted |
| Actuation | No actuation |
| Elastomer | EPDM |
| Product wetted steel part | 1.4404 (316L) |
| Dimension a1 mm | 292 |
| Dimension a1 inch | 11.50 |
| Dimension b mm | 195 |
| Dimension b inch | 7.68 |
| Dimension e mm | 117 |
| Dimension e inch | 4.61 |
| Dimension g mm | 155 |
| Dimension g inch | 6.10 |
| Dimension k mm | 330 |
| Dimension k inch | 12.99 |
| Dimension m mm | 35 |
| Dimension m inch | 1.38 |
| Dimension t inch | 0.09 |
| Dimension t mm | 2 |
| Outer diameter mm | 101.6 |
| Inner diameter mm | 97.6 |
| Weight – Net (Kg) | 24 kg |
