KOLTEK VALVE AH53-38-W/W/W- – KOLTEK VALVE AH53-38-W/W/W- – EPDM-316L
Technical Details
| Connection type | Welding ends |
| Size mm | 38 |
| Size inch | 1.5 |
| Inside surface quality | Ra ≤ 0.4 μm |
| Outside surface quality | Blasted Ra<1.6 |
| Actuation | No actuation |
| Elastomer | EPDM |
| Product wetted steel part | 1.4404 (316L) |
| Dimension a1 mm | 149 |
| Dimension a1 inch | 5.87 |
| Dimension b mm | 90 |
| Dimension b inch | 2.56 |
| Dimension e mm | 56 |
| Dimension e inch | 2.20 |
| Dimension g mm | 74.5 |
| Dimension g inch | 2.76 |
| Dimension k mm | 130 |
| Dimension k inch | 5.12 |
| Dimension m mm | 20 |
| Dimension m inch | 0.79 |
| Dimension t inch | 0.05 |
| Dimension t mm | 1.65 |
| Outer diameter mm | 38.1 |
| Inner diameter mm | 34.8 |
| Weight – Net (Kg) | 2.78 kg |
