KOLTEK VALVE DH53 W/W/W DN25 – KOLTEK VALVE DH53 W/W/W DN25 – EPDM 316L
Technical Details
| Actuation | No actuation |
| Connection type | Welding ends |
| Dimension a1 inch | 4.57 |
| Dimension a1 mm | 116 |
| Dimension b inch | 2.56 |
| Dimension b mm | 65 |
| Dimension e inch | 1.65 |
| Dimension e mm | 42 |
| Dimension g inch | 2.51 |
| Dimension g mm | 64.5 |
| Dimension k inch | 5.12 |
| Dimension k mm | 130 |
| Dimension m inch | 0.87 |
| Dimension m mm | 22 |
| Dimension t inch | 0.06 |
| Dimension t mm | 1.5 |
| Elastomer | EPDM |
| Inner diameter mm | 26 |
| Inside surface quality | Ra ≤ 0.8 μm |
| Outer diameter mm | 29 |
| Outside surface quality | Blasted |
| Product wetted steel part | 1.4404 (316L) |
| Size din | DN25 |
| Size inch | 1.14 |
| Size mm | 29 |
| Weight – Net (Kg) | 1.8 kg |
