KOLTEK VALVE MH53 NW50 EPDM – KOLTEK VALVE MH53 NW50 EPDM – MOGEMA 316L
Technical Details
| Connection type | Welding ends |
| Size mm | 53 |
| Size inch | 2.09 |
| Size din | DN50 |
| Inside surface quality | Ra ≤ 0.8 μm |
| Outside surface quality | Blasted |
| Actuation | No actuation |
| Elastomer | EPDM |
| Product wetted steel part | 1.4404 (316L) |
| Dimension a1 mm | 161 |
| Dimension a1 inch | 6.34 |
| Dimension b mm | 102 |
| Dimension b inch | 4.02 |
| Dimension e mm | 62 |
| Dimension e inch | 2.44 |
| Dimension g mm | 82.5 |
| Dimension g inch | 3.25 |
| Dimension k mm | 180 |
| Dimension k inch | 7.09 |
| Dimension m mm | 23 |
| Dimension m inch | 0.91 |
| Dimension t inch | 0.07 |
| Dimension t mm | 1.5 |
| Outer diameter mm | 53 |
| Inner diameter mm | 50 |
| Weight – Net (Kg) | 5.38 kg |
