MEMBRANE SAMPLE VALVE – MANUAL+MICRO PORT TYPE P (DN25) 0-10BAR 1.4404
Technical Details
| Product Model | SB Membrane sampling valve w. micro port |
| Sampling valves body type | Type P |
| Body combination | Micro Sample Port |
| Size din | DN25 |
| Product wetted steel part | 1.4404 (316L) |
| Other steel parts | 1.4307 (304) |
| Membrane | EPDM |
| Outside surface quality | Ra ≤ 0.8 μm |
| Temperature range | 1 – 130 |
| Temperature range fahrenheit | 33.8 – 266 |
| Max product pressure | 10 |
| Max product pressure psi | 145 |
| Max sterilization temperature | 121 |
| Max sterilization temperature psi | 249.8 |
| Dimension a mm | 26 |
| Dimension a inch | 1.02 |
| Dimension b mm | 29 |
| Dimension b inch | 1.14 |
| Dimension w mm | 65.2 |
| Dimension w inch | 2.57 |
| Dimension x mm | 82.5 |
| Dimension x inch | 3.25 |
| Dimension y mm | 6.80 |
| Dimension y inch | 0.27 |
| Dimension z mm | 87.5 |
| Dimension z inch | 3.44 |
| Weight – Net (Kg) | 0.669 kg |
