MICRO SAMPLE PORT TYPE T – WITH RED SILICONE PLUG 1.4404
Technical Details
| Product Model | SB Micro sampling port |
| Sampling valves body type | Type T |
| Elastomer | Q (Silicone) |
| Product wetted steel part | 1.4404 |
| Outside surface quality | Ra ≤ 0.8 μm |
| Long remark | Type T w/red silicone plug |
| Temperature range | 1 – 110 |
| Temperature range fahrenheit | 33 – 230 |
| Max product pressure | 6 |
| Max product pressure psi | 87 |
| Dimension a mm | 47.7 |
| Dimension a inch | 1.88 |
| Dimension b mm | 38 |
| Dimension b inch | 1.49 |
| Dimension c mm | 30 |
| Dimension c inch | 1.18 |
| Dimension d mm | 20 |
| Dimension d inch | 0.79 |
| Dimension e mm | 25 |
| Dimension e inch | 1 |
| Weight – Net (Kg) | 0.157 kg |
