NON-RETURN VALVE LKC-2-DIN – 32676 CLAMP -DN25-FPM-316L
Technical Details
| Certification | ATEX |
| Classification | II 2 G D* |
| Connection size | 25 |
| Connection size inch | 1 |
| Connection type | Clamp ends |
| Dimension a inch | 2.46 |
| Dimension a mm | 62.5 |
| Dimension h inch | 3.23 |
| Dimension h mm | 72.0 |
| Dimension t inch | 0.06 |
| Dimension t mm | 2 |
| Elastomer | FPM (Viton) |
| Inner diameter inch | 0.89 |
| Inner diameter mm | 26.0 |
| Inside surface quality | Ra ≤ 0.8 μm |
| Installation recommendations | Vertical position |
| Max product pressure | 1000 kPa (10 bar) |
| Max product pressure psi | 14.5 PSI |
| Max temperature | 140° C (EPDM) |
| Max temperature fahrenheit | 284°F (EPDM) |
| Min temperature | -10° C |
| Min temperature fahrenheit | 14°F |
| Outer diameter inch | 1.00 |
| Outer diameter mm | 30.0 |
| Outside surface quality | Bright |
| Product wetted steel part | 1.4404 (316L) |
| Size din | DN25 |
| Weight – Net (Kg) | 0.47 kg |
