PERSONNEL ACCESS LKD-532X432 – -060-N-1.4404-R
Technical Details
| Range | Oval covers |
| Size mm | 532×432 |
| Size inch | 20.94×17.01 |
| Material | 1.4404 (316L) |
| Gasket material | NBR |
| Frame height | 60 |
| Handle design | V-handle |
| Handle material | Stainless steel |
| Hinge position | External |
| Hinge direction | Right hand hinged |
| Inside surface quality | Acid pickled to Ra≤0.8 µm |
| Outside surface quality | Acid pickled to Ra≤3.0 µm |
| Pressure type | Static |
| Opening direction | Inwards, Outwards |
| Min gasket temperature c | -30 |
| Min gasket temperature f | -22 |
| Max gasket temperature c | 110 |
| Max gasket temperature f | 230 |
| Dimension a mm | 532 |
| Dimension a inch | 20.94 |
| Dimension b mm | 432 |
| Dimension b inch | 17.01 |
| Dimension t mm | 12 |
| Dimension t inch | 0.47 |
| Lid thickness mm | 3 |
| Lid thickness inch | 0.12 |
| Certificate | 3.1 Certificate |
| Position on tank | Below liquid level – on side of the tank |
| Weight – Net (Kg) | 18.5 kg |
