PERSONNEL ACCESS R-555X432 – -100-Q-1.4404
Technical Details
| Range | Rectangular covers |
| Size mm | 555×432 |
| Size inch | 21.85×17.01 |
| Material | 1.4404 (316L) |
| Gasket material | Q(Silicone) |
| Frame height | 60 |
| Handle design | V-handle |
| Handle material | Stainless steel |
| Hinge position | External |
| Inside surface quality | Electropolished on Lid to Ra≤0.8 µm and Brushed on Frame to Ra≥3.0 µm |
| Pressure type | Static |
| Opening direction | Outwards |
| Position on tank | Below liquid level – on side of the tank |
| Certificate | 3.1 Certificate |
| Min gasket temperature c | -50 |
| Min gasket temperature f | -58 |
| Max gasket temperature c | 200 |
| Max gasket temperature f | 392 |
| Dimension a mm | 432 |
| Dimension a inch | 17.01 |
| Dimension b mm | 555 |
| Dimension b inch | 21.85 |
| Dimension f mm | 60 |
| Dimension f inch | 2.36 |
| Dimension g mm | no |
| Dimension t1 mm | 12 |
| Dimension t1 inch | 0.47 |
| Dimension t2 mm | 3 |
| Dimension t2 inch | 0.12 |
| Weight – Net (Kg) | 19 kg |
