PRESSURE RELIEF VALVE – @75/3″ FLANGE TYPE 2,1BAR
Technical Details
| Nominal size mm | 75 |
| Nominal size inch | 3 |
| Bolts | 4xM16 |
| Opening pressure range bar | 2.1 |
| Opening pressure range psi | 30.46 |
| Valve type | Flange mounted valve |
| Inside surface quality | Ra ≤ 0.8 μm |
| Product wetted steel part | 1.4404 (316L) |
| Elastomer | EPDM |
| Outer diameter mm | 200 |
| Outer diameter inch | 7.87 |
| Inner diameter mm | 75 |
| Inner diameter inch | 2.95 |
| Dimension bc mm | 165 |
| Dimension bc inch | 6.50 |
| Dimension h1 mm | 375 |
| Dimension h1 inch | 14.76 |
| Dimension h2 mm | 30 |
| Dimension h2 inch | 1.36 |
| Dimension w mm | 740 |
| Dimension w inch | 29.13 |
| Weight – Net (Kg) | 24.8 kg |
