SAMPLING VALVE SIZE 10 38MM – TANK MOUNTED Q (SILICONE) DOUBLE SEAT WITH HANDLE
Technical Details
| Size mm | 38 |
| Connection type | Tank mounted |
| Body combination | Double Seat handle |
| Size interface | 10 |
| Elastomer | Q (Silicone) |
| Product wetted steel part | 1.4404 (316L) |
| Hfh application | Hygienic |
| Inside surface quality | Ra ≤ 0.8 μm |
| Outside surface quality | Polished |
| Temperature range | 1 – 130 |
| Temperature range fahrenheit | 33.8 – 266 |
| Max working pressure | 6 |
| Max working pressure psi | 87 |
| Min working pressure | 0 |
| Min working pressure psi | 0 |
| Dimension a mm | 111.4 |
| Dimension a inch | 4.39 |
| Dimension b mm | 38 |
| Dimension b inch | 1.50 |
| Dimension d mm | 14 |
| Dimension d inch | 0.55 |
| Dimension e mm | 10 |
| Dimension e inch | 0.39 |
| Dimension f mm | 85.8 |
| Dimension f inch | 3.38 |
| Dimension g mm | 53.2 |
| Dimension g inch | 2.09 |
| Dimension h mm | 25 |
| Dimension h inch | 0.98 |
| Weight – Net (Kg) | 1 kg |
