SEAT VALVE SSSV DN/OD 12,7 CL – 30 WINGNUT CLAMP NC EPDM 316L POLISHED WITH US AIRFITTINGS
Technical Details
| Actuation | Pneumatic |
| Actuator function | Normally closed |
| Air pressure | 100 to 700 kPa (1 to 7 bar) |
| Body function | Shut-off |
| Certification | 3A |
| Clamp type | Wing nut |
| Connection type | Clamp |
| Elastomer | EPDM |
| Inside surface quality | Ra ≤ 0.5 μm |
| Port configuration | 300 |
| Product wetted steel part | 1.4404 (316L) |
| Size inch | 0.5" |
| Size iso | 12.7 |
| Valve assembled | Yes |
| Temperature range | -10 °C to +140 °C |
| Temperature range fahrenheit | 14 °F to + 284 °F |
| Product Model | Unique SSSV ISO 12.7 mm |
| Outside surface quality | Semi-bright |
| Other steel parts | 1.4307 (304) |
| Other seals | NBR |
| Max product pressure | 1000 kPa (10 bar) |
| Max product pressure psi | 145 PSI |
| Min product pressure psi | Full vacuum |
| Min product pressure | Full vacuum |
| Dimension a1 inch | 6.78 |
| Dimension a1 mm | 172.2 |
| Dimension e1 inch | 1.17 |
| Dimension e1 mm | 29.8 |
| Dimension f1 inch | 0.28 |
| Dimension f1 mm | 7 |
| Dimension h inch | 0.28 |
| Dimension h mm | 57 |
| Dimension t inch | 0.06 |
| Dimension t mm | 1.6 |
| Outer diameter inch | 0.50 |
| Outer diameter mm | 12.7 |
| Inner diameter mm | 9.5 |
| Weight – Net (Kg) | 1.57 kg |
