SEAT VALVE SSSV DN/OD 19 W/W – 30 WING NUT CLAMP MANUAL EPDM 316L
Technical Details
| Actuation | Manual |
| Actuator function | Standard |
| Air pressure | 100 to 700 kPa (1 to 7 bar) |
| Body function | Shut-off |
| Certification | 3A |
| Clamp type | Wing nut |
| Connection type | Weld |
| Elastomer | EPDM |
| Inside surface quality | Ra ≤ 0.5 μm |
| Port configuration | 300 |
| Product wetted steel part | 1.4404 (316L) |
| Size inch | 0.75" |
| Size iso | 19 |
| Valve assembled | Yes |
| Temperature range | -10 °C to +140 °C |
| Temperature range fahrenheit | 14 °F to + 284 °F |
| Product Model | Unique SSSV ISO 19.0 mm |
| Outside surface quality | Semi-bright |
| Other steel parts | 1.4307 (304) |
| Other seals | NBR |
| Max product pressure | 1000 kPa (10 bar) |
| Max product pressure psi | 145 PSI |
| Min product pressure psi | Full vacuum |
| Min product pressure | Full vacuum |
| Dimension a1 mm | 112.7 |
| Dimension e1 inch | 1.18 |
| Dimension e1 mm | 29.9 |
| Dimension h inch | 1.38 |
| Dimension h mm | 35 |
| Dimension t inch | 0.06 |
| Dimension t mm | 1.6 |
| Outer diameter inch | 0.75 |
| Outer diameter mm | 19 |
| Inner diameter mm | 15.8 |
| Weight – Net (Kg) | 0.61 kg |
