SIGHT GLASS UNION W/MINIVISION – LIGHT FITTINGS TYPE 70 DN65
Technical Details
| Product Model | Tank sight glasses Union type |
| Size din | DN65 |
| Material | 1.4301 (304) |
| Gasket material | EPDM |
| Certificate | 3.1 Certificate |
| Standard | DIN 11851 |
| Bulb type | Halogen 50W/24V |
| Push button | Without push button |
| Dimension a inch | 5.55 |
| Dimension a mm | 141 |
| Dimension b inch | 5.28 |
| Dimension b mm | 134 |
| Dimension c inch | 4.61 |
| Dimension c mm | 117 |
| Dimension d inch | 2.76 |
| Dimension d mm | 70 |
| Weight – Net (Kg) | 1.63 kg |
