SIGHTGLASS DN 200 DIN 28120 – EPDM 3.1 FOR MINIVISION GB BKVLR
Technical Details
| Product Model | Tank sight glasses DIN 28120 sight glass |
| Material | 1.4404 (316L) |
| Gasket material | EPDM |
| Certificate | 3.1 Certificate |
| Standard | DIN 28120 |
| Inside surface quality | Semi bright Ra≤0.8 µm |
| Outside surface quality | Semi bright Ra≤1.6 µm |
| Dimension d inch | 13.39 |
| Dimension d mm | 340 |
| Dimension d1 inch | 8.86 |
| Dimension d1 mm | 225 |
| Dimension d4 inch | 9.84 |
| Dimension d4 mm | 250 |
| Dimension h1 inch | 1.38 |
| Dimension h1 mm | 35 |
| Dimension h2 inch | 1.42 |
| Dimension h2 mm | 36 |
| Dimension k inch | 11.61 |
| Dimension k mm | 295 |
| Dimension s inch | 1.18 |
| Dimension s mm | 30 |
| Weight – Net (Kg) | 31.45 kg |
