SIGHTGLASS DN65 DIN 11851 – EPDM 3,1B 6BAR/280°C F.MINIVISION BKVLR
Technical Details
| Product Model | Tank sight glasses Union type |
| Size din | DN65 |
| Material | 1.4404 (316L) |
| Gasket material | EPDM |
| Certificate | 3.1 Certificate |
| Standard | DIN 11851 |
| Bulb type | Excluding miniVISION |
| Push button | Without push button |
| Inside surface quality | Semi bright Ra≤0.8 µm |
| Outside surface quality | Semi bright Ra≤1.6 µm |
| Dimension a inch | 1.81 |
| Dimension a mm | 46 |
| Dimension d inch | 4.41 |
| Dimension d mm | 112 |
| Outer diameter inch | 2.83 |
| Outer diameter mm | 72 |
| Inner diameter inch | 2.6 |
| Inner diameter mm | 66 |
| Weight – Net (Kg) | 1.05 kg |
