TEE-RED 63.5-51-POL-316L – TEE-SHORT-ISO2037
Technical Details
| Range | Tees |
| Product Model | ISO EN 10357-D Tees Reducing Short |
| Size | 63.5 mm |
| Second size | 51.0 mm |
| Material | 1.4404 (316L) |
| Finish | POL (ID=0.8/OD=1.0) |
| Connection type | Weld ends |
| Standard | ISO 2037 |
| OD/ID x t | 63.50/60.30 x 1.60 |
| OD1/ID1 x t1 | 63.50/60.30 x 1.60 |
| OD2/ID2 x t2 | 51/48.60 x 1.20 |
| Dimension L1, mm | 105 |
| Dimension L2, mm | 66.50 |
| OD2 | 51 |
| Weight – Net (Kg) | 0.53 kg |
