THINK-TOP DEVICE.NET 11-25.VDC – 3MV8VDC3/2 1/4 INCH
Technical Details
| Number of solenoids | 3 |
| Solenoid type | 3/2 |
| Air fitting inch | ¼ |
| Communication interface | Device Net |
| Electric connection | Cable Gland |
| Sensor accuracy mm | ± 0.1 |
| Air supply bar | 3-9 |
| Supply voltage | 11 – 25 VDC |
| Air fitting material | Nickel plated |
| Other steel parts | 1.4307 (304) |
| Plastic part material | Nylon PA 12 |
| Gasket material | Nitrile / NBR |
| Protection class ip | IP67 |
| Protection class nema | 4X, 6 |
| Dimension a inch | 7 |
| Dimension a mm | 172 |
| Dimension b inch | 5.12 |
| Dimension b mm | 137 |
| Dimension c inch | 12 |
| Dimension c mm | 300 |
| Dimension d inch | 9 |
| Dimension d mm | 225 |
| Weight – Net (Kg) | 1.23 kg |
