TTV20 S CONTR TOP C DIG M12 – DIGITAL
Technical Details
| Air supply bar | 3-8 |
| Automation type | ThinkTop V20 |
| Communication interface | DC PNP |
| Dimension a inch | 4.84 |
| Dimension a mm | 123 |
| Dimension b inch | 4.13 |
| Dimension b mm | 105 |
| Electric connection | M12 |
| M12 chassis connector material | Stainless steel, Gold plated pins |
| Mean time to failure mttf | 224 years |
| Plastic part material | Nylon PA 12 |
| Product Model | ThinkTop V20 Digital |
| Protection class ip | IP69K |
| Protection class nema | 4, 4X, 6 |
| Sensor accuracy mm | ± 0.1 |
| Supply voltage | 24 VDC ± 10% |
| Weight – Net (Kg) | 0.51 kg |
| Working temperature range c | -10 °C to +60 °C |
| Working temperature range f | +14°F to +140°F |
