TTV50 24V DIG 0SV . – THINKTOP V50 DIGITAL 24VDC PNP 0 SOLENOID
Technical Details
| Air fitting inch | ¼ |
| Air fitting material | Nickel plated |
| Air pressure bar | 6-8 |
| Air supply bar | 3-8 |
| Automation type | ThinkTop V50 |
| B10 data | 5 million cycles |
| Certificate | UL/CSA Certificate: E174191 |
| Communication interface | DC PNP |
| Dimension a inch | 4.84 |
| Dimension a mm | 123 |
| Dimension b inch | 4.13 |
| Dimension b mm | 105 |
| Dimension c inch | 7.87 |
| Dimension c mm | 200 |
| Dimension d inch | 5.91 |
| Dimension d mm | 150 |
| Electric connection | Cable Gland |
| M12 chassis connector material | Stainless steel, Gold plated pins |
| Max wire diameter mm2 | 0.75 (AWG20) |
| Mean time to failure mttf | 224 years |
| Nominal power (W) | 0.3 W |
| Number of solenoids | 0 |
| Operating recommendation | Operate once a month to prevent dry-out |
| Other steel parts | 1.4301 (304) |
| Plastic part material | Nylon PA 12 |
| Product Model | ThinkTop V50 Digital |
| Protection class ip | IP69K |
| Protection class nema | 4, 4X, 6 |
| Sensor accuracy mm | ± 0.1 |
| Shock (G) | 100 |
| Solenoid type | None |
| Vibration (Hz) | 18 Hz-1 kHz |
| Weight – Net (Kg) | 0.58 kg |
| Working temperature range c | -10°C to +60°C |
| Working temperature range f | +14°F to +140°F |
