VALVE-DH53-NW40-316L-EPDM – VALVE-DH53-NW40-316L-EPDM – WITH DIN MALE PARTS
Technical Details
| Connection type | Male/Male |
| Size mm | 41 |
| Size inch | 1.61 |
| Size din | DN40 |
| Inside surface quality | Ra ≤ 0.8 μm |
| Outside surface quality | Blasted |
| Actuation | No actuation |
| Elastomer | EPDM |
| Product wetted steel part | 1.4404 (316L) |
| Dimension a1 mm | 149 |
| Dimension a1 inch | 5.87 |
| Dimension b mm | 90 |
| Dimension b inch | 2.56 |
| Dimension e mm | 56 |
| Dimension e inch | 2.20 |
| Dimension g mm | 80 |
| Dimension g inch | 3.15 |
| Dimension k mm | 130 |
| Dimension k inch | 5.12 |
| Dimension m mm | 22 |
| Dimension m inch | 0.87 |
| Dimension t inch | 0.05 |
| Dimension t mm | 1.5 |
| Outer diameter mm | 41 |
| Inner diameter mm | 38 |
| Weight – Net (Kg) | 4.9 kg |
