Connection type: Clamp ends
Design: B2CMP
Dimension A: 41.30
Dimension A, Inch: 1.63
Finish: SF4(PM) (ID=15EP/OD=32µin)
Material: 316L
OD/ID x t: 12.70/9.40 x 1.65
OD/ID x t, inch: 0.500/0.370 x 0.065
Product model: Tri-Clover BPE Bends 90
Range: Bends
Size: 0.5″
Standard: ASME BPE
Weight – Net (Kg): 0.05 kg
Log in or register to view prices.
Log in or register to view and purchase products.
B2CMP-1/2-316L-PM – BPE TC 90 15RAEP/POL OD SF4
| Connection type | Clamp ends |
| Design | B2CMP |
| Dimension A | 41.30 |
| Dimension A, Inch | 1.63 |
| Finish | SF4(PM) (ID=15EP/OD=32µin) |
| Material | 316L |
| OD/ID x t | 12.70/9.40 x 1.65 |
| OD/ID x t, inch | 0.500/0.370 x 0.065 |
| Product model | Tri-Clover BPE Bends 90 |
| Range | Bends |
| Size | 0.5" |
| Standard | ASME BPE |
| Weight – Net (Kg) | 0.05 kg |
B2CMP-1/2-316L-PM
