Connection type: TCxRTC
Design: B7RMPS
Dimension A: 73.00
Dimension A, Inch: 2.88
Dimension B: 34.90
Dimension B, Inch: 1.38
Finish: SF1(PL) (ID=20/OD=32µin)
Material: 316L
OD/ID x t: 38.10/34.80 x 1.65
OD/ID x t, inch: 1.5/1.37 x 0.065
Product model: Tri-Clover BPE Reducing Tees Short
Range: Tees
Second size: 1″
Size: 1.5″
Standard: ASME BPE
Weight – Net (Kg): 0.76 kg
Log in or register to view prices.
Log in or register to view and purchase products.
B7RMPS-1 1/2 X 1-316L-PL – BPE TC S/O RED T 20RA SF1
| Connection type | TCxRTC |
| Design | B7RMPS |
| Dimension A | 73.00 |
| Dimension A, Inch | 2.88 |
| Dimension B | 34.90 |
| Dimension B, Inch | 1.38 |
| Finish | SF1(PL) (ID=20/OD=32µin) |
| Material | 316L |
| OD/ID x t | 38.10/34.80 x 1.65 |
| OD/ID x t, inch | 1.5/1.37 x 0.065 |
| Product model | Tri-Clover BPE Reducing Tees Short |
| Range | Tees |
| Second size | 1" |
| Size | 1.5" |
| Standard | ASME BPE |
| Weight – Net (Kg) | 0.76 kg |
B7RMPS-1 1/2 X 1-316L-PL
