Connection type: Weld ends
Design: Standard
Dimension L: 78.00
Dimension R, mm: 55.00
Finish: HSF2 (ID=0.8/OD=1.6)
Material: 1.4404 (316L)
OD/ID x t: 35.00/32.00 x 1.50
Product Model: Fit to DIN Bends 90
Range: Bends
Size: DN32
Standard: Fit to EN10357-A
Weight – Net (Kg): 0.15 kg
Log in or register to view prices.
Log in or register to view and purchase products.
BEND 90 DN32 HSF2 1.4404 – FIT TO EN10357-A TUBE
| Connection type | Weld ends |
| Design | Standard |
| Dimension L | 78.00 |
| Dimension R, mm | 55.00 |
| Finish | HSF2 (ID=0.8/OD=1.6) |
| Material | 1.4404 (316L) |
| OD/ID x t | 35.00/32.00 x 1.50 |
| Product Model | Fit to DIN Bends 90 |
| Range | Bends |
| Size | DN32 |
| Standard | Fit to EN10357-A |
| Weight – Net (Kg) | 0.15 kg |
BEND 90 DN32 HSF2 1.4404
