INSPECTION PORT R-235X185-040 – -E-1.4301
Technical Details
| Certificate | 3.1 Certificate |
| Connection type | Weld |
| Dimension a inch | 7.28 |
| Dimension a mm | 185 |
| Dimension b inch | 9.25 |
| Dimension b mm | 235 |
| Dimension c inch | 13.11 |
| Dimension c mm | 333 |
| Dimension e inch | 5.63 |
| Dimension e mm | 143 |
| Dimension f inch | 1.57 |
| Dimension f mm | 40 |
| Dimension g inch | 0.51 |
| Dimension g mm | 13 |
| Dimension h inch | 0.67 |
| Dimension h mm | 17 |
| Dimension t1 inch | 0.2 |
| Dimension t1 mm | 5 |
| Dimension t2 inch | 0.05 |
| Dimension t2 mm | 1.2 |
| Frame height | 40 |
| Gasket material | EPDM |
| Handle design | Handwheel |
| Handle material | Polymer |
| Hinge position | External |
| Inside surface quality | Electropolished on Lid to Ra≤0.8 µm and Brushed on Frame to Ra≥3.0 µm |
| Material | 1.4301 (304) |
| Max gasket temperature c | 90 |
| Max gasket temperature f | 194 |
| Min gasket temperature c | -15 |
| Min gasket temperature f | 5 |
| Opening direction | Outwards |
| Position on tank | Below liquid level – on side of the tank |
| Pressure type | Static |
| Range | Rectangular covers |
| Size inch | 9.25×7.28 |
| Size mm | 235×185 |
| Weight – Net (Kg) | 3.6 kg |
